Parameters
| Model |
Capacity (m³/h) |
Bucket capacity (L) |
Pitch between buckets (mm) |
Speed of bucket (m/s) |
Size of material (mm) |
| NE15 |
15 |
2.5 |
203.2 |
0.5 |
50 |
| NE30 |
30 |
7.8 |
304.8 |
0.5 |
65 |
| NE50 |
50 |
15.7 |
304.8 |
0.5 |
65 |
| NE100 |
110 |
35.0 |
400 |
0.5 |
95 |
| NE150 |
170 |
52.2 |
400 |
0.5 |
95 |
| NE200 |
220 |
84.6 |
500 |
0.5 |
125 |
| NE300 |
320 |
127.5 |
500 |
0.5 |
125 |
| NE400 |
400 |
182.6 |
600 |
0.5 |
145 |
| NE500 |
500 |
260.9 |
700 |
0.5 |
165 |
| NE600 |
600 |
330.2 |
700 |
0.5 |
165 |
| NE800 |
800 |
501.8 |
800 |
0.5 |
195 |
Distinctive Features
1. High elevating efficiency: This elevator needs low driving power, adopting inflow feeding and induction unloading, without feeding back.<br/>
2. Wide usage: This machine requires less in materials’ species and property, not only can lift general powder and little particles, but high polishing materials. <br/>
3. Reliable operation: The advanced design and processing method assure whole machine’s reliability. This machine had been tested for non-fault time exceed 20000 hours.<br/>
4.Long service life: This elevator adopts inflow feeding and no need to excavating materials with hopper. So, there are less extrusion and collision between materials, which would reduce machinery abrasion.
Application Industries
Widely applied in vast industries like metallurgy, chemical industry,building materials, mine, grain and vegetable oil, food, fodder, plastic and medicine.
1. Metallic and non-metallic ores: bauxite, coal, sand, gravel cement, gypsum, limestone, etc.
2. Food products: sugar, flour, coffee, salt, etc.
3. Chemical processing products: fertilizers, phosphates, agricultural lime, soda ash, etc.
4. Pulp and paper products: wood chips.
